In Line Booster
für Mikrofone mit niedriger Empfindlichkeit
für Mikrofone mit niedriger Empfindlichkeit
![](https://cdn.myportfolio.com/dcf4154a-b7d4-4234-ba91-882b37c978b2/0e89e6cf-7a2b-42c6-ad8e-2683864e3e53_rw_3840.png?h=d2edd4667d2d6ecfef691aff4967b0b3)
![](https://cdn.myportfolio.com/dcf4154a-b7d4-4234-ba91-882b37c978b2/6c70cf64-3667-4fe4-93e2-45e9554441bc_rw_3840.png?h=b32f7cebecc72a3fdde25212bdb35ea5)
BOM:
1x Neutrik XLR3m - NC3MAH
1x Neutrik XLR3f - NC3FAH2
2x Folienkondensator 1nF / 63V - C1, C2
2x Elektrolythkondensator 22uF / 63V - C3, C4
1x Elektrolythkondensator 100uF / 63V - C5
2x Elektrolythkondensator 22uF / 63V - C3, C4
1x Elektrolythkondensator 100uF / 63V - C5
2x Metallschichtwiderstand 10k 1% - R1, R2
2x Metallschichtwiderstand 1k 1% - R3, R4
2x Metallschichtwiderstand 2k7 1% - R5, R6
2x Metallschichtwiderstand 470k 1% - R7, R8
2x Metallschichtwiderstand 1k 1% - R3, R4
2x Metallschichtwiderstand 2k7 1% - R5, R6
2x Metallschichtwiderstand 470k 1% - R7, R8
2x FET 2N3819 - Q1, Q2
2x PNP 2N5087 - Q3, Q4
2x PNP 2N5087 - Q3, Q4
